TM 9-2350-247-20-2
0207 00
INSTALLATION
1.
Install muffler (1) in carrier and align with plate (2).
2.
Attach air filter duct clamp (3) to muffler (1) and tighten two nuts (4).
3.
Secure plate (2) with four screws (5), eight washers (6), and four new lock nuts (7).
4.
Secure muffler (1) to rear engine bulkhead (8) with four screws (9), eight washers (10), and four new lock nuts (11).
FOLLOW-THROUGH STEPS
1.
Install top access cover and grilles (see your -10).
2.
3.
4.
Install rear compartment cover and bows (as required) (WP 0417 00).
END OF TASK
