INSTALL (cont) - TM-9-2350-261-20-2

R E P L A C E R E A R M A I N W I R I N G H A R N E S S ( M 1 1 3 A 2 , M 9 0 1 A 1 , A ND M 1 0 5 9 O N L Y)

TM-9-2350-261-20-2 Carrier Personnel Full Tracked Armored M113A2 2350-01-068-4077 Carrier Command Post Light Tracked M577A2 2350-01-068-4089 Manual
Page Navigation
267

TM 9-2350-261-20-2 Insert harness (1) through hole in rear plate (2). Install harness guard (3) on top of rear hull. Secure with screw (4), washer (5), and new lockwasher (6). Route harness (1) along top of right fuel tank (7) and install harness bracket (8) over harness (1). Secure with two screws (9), washers (10), and new lockwashers (11). 121. 122. 123. Connect circuit 31 lead (12) to fuel transmitter lead (13) On right fuel tank (7). Connect circuit 23 and 24 leads (14 and 15) to right tail light leads (16 and 17). Install harness guard (18) over harness (1) on right fuel tank (7). Secure with two screws (19), washers (20), and new lockwashers (21). FOLLOW-THROUGH STEPS 1. Install rear floor plate (page 24-38). 4. Z. Connect battery ground lead (page 13-2). 5. 3. Turn MASTER SWITCH ON and start engine (see your -10). 6. END OF TASK Check that electrical system works properly (see your -10). Raise and lock ramp (see your –10). Stop engine (see your -10). 12-118.20 Change 2 118. 119. 118.
