TM 9-2350-247-20-2

REPLACE DIFFERENTIAL AND MOUNTS (M548A1) -- Continued

0342 00

Connect differential high oil temperature switch lead (1) to main wiring harness.

FOLLOW-THROUGH STEPS

Connect transmission range selector link from range selector arm and cross-shaft and install link (WP 0315 00).

Connect accelerator pedal link from control arm and cross-shaft and install link (WP 0197 00).

Connect fuel shutoff cable to engine (WP 0194 00).

Install heater to defroster duct, if personnel heater is installed (WP 0453 00).

Install pivot steering brakes and brake disks (WP 0373 00), (WP 0374 00).

Install hull bottom access cover (WP 0383 00).

Install winch transfer gearcase (WP 0413 00).

Install winch propeller shaft (WP 0412 00).

Lower center seat (see your -10).

10. Install cab floor plates (WP 0394 00).

0342 00-4
