TM 9-2350-247-20-1 WINCH DRUM DOES NOT TURN WITH DRUM CLUTCH IN “CLUTCH IN” POSITION (M548A1)—Continued 0090 00 3Y 1. Check for badly worn or broken gears. 2. Are gears in good condition? YES NO 3YN 1. Damaged gears. 2. Notify your supervisor. 4Y 1. Check drag brake adjustment (WP 0408 00). 2. Has drag brake been adjusted? YES NO 4YN 1. Adjust drag brake (WP 0408 00). 2. Verify no faults found. 5Y 1. Replace sheared winch yoke shear pin (WP 0412 00). 2. Verify no faults found. 0090 00-2
