TM 9-2350-277-34 REPLACE TRANSMISSION — Continued 0035 00 15. Remove transmission from blocks and place on power plant stand (2). Use sling (1) and suitable lifting device. 16. Place engine and transmission 1 to 2 inches apart and using screwdriver, rotate flywheel so that flywheel grooves line up with splined coupling grooves. Slide engine and transmission together and secure with 10 new self-locking bolts (3), 10 washers (4), screw (7), three washers (6), and two new locknuts (5). TIGHTEN SCREW WITH LOCKNUT TO 38-41 FT-LB (52-56 N m) TORQUE. Tighten oil outlet hose. Use adjustable wrench. 17. Connect variable speed drive clutch supply hose (9) to elbow (10) on transmission filter case. 0035 00-15
