PROJECTILE RACK PULL TEST (CONTINUED)

CHAPTER 14 MISCELLANEOUS HULL COMPONENTS

TM-9-2350-267-34 Hull Powerpack Drive Controls Tracks Suspension and Associated Components Carrier Ammunition Tracked Manual
Page Navigation
267

PROJECTILE RACK PULL TEST (CONTINUED) J K Inspect tube (7) for damage or deformation. Inspect locking shoe (13) for separation of plastisol coating (14). Test can be considered a pass if no irregularities are found. If test fails for any reason, refer to Projectile Rack Repair (p 13-1). Remove projectile rack (1) from test stand (2) by removing two rods (3), two flat washers (4) and two lockwashers (5). 13-11/(13-12 blank) Change 1 TM 9-2350-267-34
