TM 9-2350-261-20-4
REPLACE ADAPTER ACCESS PLATE TO GENERATOR ELECTRICAL CABLE
0703 00
ASSEMBLY (M1059 ONLY) -- Continued
INSTALLATION
WARNING
Before you do any maintenance, discharge all capacitors to ground or electrical shock could
injure personnel.
NOTE
Left and right cable assemblies are replaced the same way.
1.
Connect cable assembly (1) to smoke generator cover assembly connector 5J1 (3).
2.
Connect cable assembly (1) to adapter access plate connector (2).
FOLLOW-THROUGH STEPS
1.
2.
Connect battery ground lead (WP 0294 00).
3.
Set circuit breaker CB1 to ON. See TM 3-1040-283-10.
4.
END OF TASK
