TM 9-2350-261-20-4
0700 00
(M1059 ONLY) -- Continued
INSTALLATION
WARNING
Before you do any maintenance, discharge all capacitors to ground or electrical shock could
injure personnel.
Connect cable assembly (1) to air compressor cable assembly connector (3).
1.
Connect cable assembly (1) to control panel assembly connector 1J2 (2).
2.
Secure cable assembly (1) to hull with six clamps (6), screws (4), and new lockwashers (5).
3.
FOLLOW-THROUGH STEPS
1.
Connect battery ground lead (WP 0294 00).
2.
Set circuit breaker CB1 to ON. See TM 3-1040-283-10.
END OF TASK
