TM 9-2350-247-34 REPAIR MULTIPIN CONNECTORS — Continued 0006 00 NOTE Make sure leads pass through proper lettered hole in grommet. 4. Solder leads (3) in contacts (5) and press contacts into grommet (4). Check leads for continuity. 5. Align and install grommet (4) in receptacle (2). Secure with nut (1). 0006 00-4
