TM 9-2350-247-20-2
REPLACE TORSION BAR ANCHOR -- Continued
0350 00
INSTALLATION
1.
Place torsion bar anchor (2) on hull mount.
2.
Install two screws (1) in anchor (2). TIGHTEN SCREWS TO 320-330 LB-FT (434-447 NM) TORQUE. Use torque
wrench.
FOLLOW-THROUGH STEPS
1.
2.
Install power plant for first and second torsion bar anchor (WP 0130 00 or WP 0131 00).
3.
4.
Road test carrier (WP 0128 00) to check that torsion bar anchor is installed properly.
END OF TASK
Change 1
