TM 9-2350-247-20-2
REPLACE TRANSMISSION SHIFT CONTROL LAMP (M548A3) -- Continued
0307 00
INSTALLATION
1.
Install new preformed packing (10) on lamp (4).
2.
Install lamp (4) into clamp (9).
3.
Install filter (5) and shield (6) properly over lamp (4). Secure by tightening screw (7) and nut (8) on clamp (9).
4.
Install cover (2) on shift control (3). Secure with two wing screws (1).
FOLLOW-THROUGH STEPS
1.
2.
END OF TASK
