TM 9-2350-277-34PATCH PANEL BOX A10 INOPERATIVE (M1068A3 ONLY)—Continued 0010 00B2Y1. Measure resistance between pins on cable W115 plug P106 (1)and posts on External Communication Box A11 (2) front panel asfollows:Post 1 (Blk) to pin A Post 1 (Red) to pin BPost 2 (Blk) to pin C Post 2 (Red) to pin DPost 3 (Blk) to pin E Post 3 (Red) to pin FPost 4 (Blk) to pin G Post 4 (Red) to pin HPost 5 (Blk) to pin J Post 5 (Red) to pin KPost 6 (Blk) to pin L Post 6 (Red) to pin MPost 7 (Blk) to pin N Post 7 (Red) to pin PPost 8 (Blk) to pin R Post 8 (Red) to pin S2. Does multimeter read 0 ohms for each measurement?YESNOB2YN1. Replace cable W115 (WP 0107 00).2. Verify no faults found.B3Y1. Verify no faults found.0010 00-4
