REPLACE OVERSIZE SCREW THREAD INSERTS WITH LOCK RING Continued

REPLACE OVERSIZE SCREW THREAD INSERTS WITH LOCK RING Continued - TM-9-2350-247-34_356

TM-9-2350-247-34 Carrier Cargo Tracked 6 Ton M548A12350010969356 (EIC: AEU) M548A3 2350013696081 (EIC: AE9) Manual
Page Navigation
303

TM 9-2350-247-34 REPLACE OVERSIZE SCREW THREAD INSERTS WITH LOCK RING — Continued 0037 00 5. Counterbore to depth of lock ring thickness plus 0.010 to 0.020 inch (.254 to .508 mm). 6. Hand tap correct size threads. 7. Use wrench (3) to install oversize insert (4) in threaded hole. 0037 00-3
