SECTION II
TM 9-2350-277-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGE
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 4202 ELECTRICAL CONTROLS
CONTINUED
FIG. 420 INVERTER HOUSING ASSEMBLY, CONTINUED
(M1068A3)
29
PAOZZ
96906
MS45904-69
WASHER, LOCK................................................................................................
6
UOC: AP3
30
PAOZZ
80204
B1821BH025C100N
SCREW, CAP, HEXAGON H ...............................................................................
6
UOC: AP3
31
PAOZZ
96906
MS35206-232
SCREW, MACHINE ...........................................................................................
4
UOC: AP3
32
PAOZZ
81349
38TB5F
TERMINAL BOARD ............................................................................................
1
UOC: AP3
33
PAOZZ
96906
MS51943-31
NUT, SELF-LOCKING, HE ..................................................................................
8
UOC: AP3
34
PAOZZ
96906
MS27183-56
WASHER, FLAT ................................................................................................
8
UOC: AP3
35
PAOZZ
96906
MS51943-33
NUT, SELF-LOCKING, HE ..................................................................................
8
UOC: AP3
END OF FIGURE
420-2
