SECTION II
TM 9-2350-277-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGE
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 1808 STOWAGE RACKS, BOXES,
STRAPS CONTINUED
FIG. 316 FIRE EXTINGUISHER MOUNT AND
RELATED HARDWARE
(M1059A3)
1
PAOZZ
19207
12313975
BRACKET, FIRE EXTING ...................................................................................
2
UOC: AP6
2
PAOZZ
96906
MS21044N4
.NUT, SELF-LOCKING, HE .................................................................................
1
UOC: AP6
3
PAOZZ
96906
MS27183-10
.WASHER, FLAT ................................................................................................
1
UOC: AP6
4
PAOZZ
80204
B1821BH025C 63N
.SCREW, CAP, HEXAGON H ..............................................................................
1
UOC: AP6
5
PAOZZ
19207
11613002-3
.WIRE ROPE ASSEMBLY, .................................................................................
1
UOC: AP6
6
PAOZZ
19207
7752865
.PIN, LOCK .......................................................................................................
1
UOC: AP6
7
PAOZZ
80204
B1821BH038C075N
SCREW, CAP, HEXAGON H ...............................................................................
8
UOC: AP6
8
PAOZZ
96906
MS27183-14
WASHER, FLAT ................................................................................................
8
UOC: AP6
END OF FIGURE
316-1
