DESCRIPTION AND USABLE ON CODE (UOC)

Figure 61. Starter and Mounting Hardware

Figure 62. Master Switch Panel (M113A3, M1059A3, M1064A3, M58, M901A3)

TM-9-2350-277-24P Carrier Personnel Full Tracked Armored M113A3 2350-01-219-7577 (EIC AE7) Carrier Command Post Light Tracked M577A3 2350-01-369-6085 (EIC AE7) Manual
Page Navigation
131

SECTION II TM 9-2350-277-24P (1) (2) (3) (4) (5) (6) ITEM SMR PART NO CODE CAGE NUMBER DESCRIPTION AND USABLE ON CODE (UOC) QTY GROUP 0603 STARTING MOTOR CONTINUED FIG. 61 STARTER AND MOUNTING HARDWARE 1 PAOZZ 72582 5130995 GASKET ........................................................................................................... 1 2 PAOFF 19207 12313371 STARTER, ENGINE, ELEC ................................................................................. 1 3 PAOZZ 96906 MS35207-261 SCREW, MACHINE 10-32UNF-2AX3/8 GR ............................................................ 1 4 PAOZZ 24617 9418228 BOLT, MACHINE 5/8-11UNC-2AX1-3/4 ................................................................ 3 5 PAOZZ 96906 MS35338-50 WASHER, LOCK................................................................................................ 3 END OF FIGURE 61-1
