SECTION II
TM 9-2350-277-24P
(1)
(2)
(3)
(4)
(5)
(6)
ITEM
SMR
PART
NO
CODE
CAGE
NUMBER
DESCRIPTION AND USABLE ON CODE (UOC)
QTY
GROUP 6715 SPECIAL ELECTRONIC
TESTING EQUIPMENT, MOUNTED OR
PORTABLE CONTINUED
FIG. 434 STE-ICE INSTALLATION, CONTINUED
(M981A3)
28
PAOZZ
96906
MS35333-40
WASHER, LOCK................................................................................................
4
UOC: AP1
29
PAOZZ
96906
MS35206-279
SCREW, MACHINE ...........................................................................................
4
UOC: AP1
30
PAOZZ
96906
MS35206-231
SCREW, MACHINE............................................................................................
4
UOC: AP1
31
PAFZZ
96906
MS21083N06
NUT, SELF-LOCKING, HE .................................................................................
1
UOC: AP1
32
PAOZZ
96906
MS21333-123
CLAMP, LOOP ...................................................................................................
1
UOC: AP1
33
PAOZZ
80204
B1821BH038F063N
SCREW, CAP, HEXAGON H ...............................................................................
1
UOC: AP1
34
PAOFF
19207
12354672
WIRING HARNESS, BRAN SEE FIG. 437 .............................................................
1
UOC: AP1
35
PAOZZ
96906
MS3367-2-9
STRAP, TIEDOWN, ELECT .................................................................................
5
UOC: AP1
36
PAOZZ
96906
MS3367-4-9
STRAP, TIEDOWN, ELECT .................................................................................
3
UOC: AP1
37
PAOZZ
19207
12258931-1
TACHOMETER, MECHANIC ...............................................................................
1
UOC: AP1
END OF FIGURE
434-2
