TM 9-2350-277-20-1STEERING LOCKED INDICATOR MALFUNCTIONS—Continued 0054 00C2Y1. Turn MASTER SWITCH to OFF.2. For solenoid-activated lock, remove harness 12354722 plug (1)from harness 12349911 jack (2). For cable-activated lock, removeharness 12369685 plug (1) from harness 1236984 jack (2).3. H: For solenoid-activated lock, push and hold solenoid plungerwhile measuring resistance.4. For solenoid-activated lock, measure resistance between harness12349911 jack (2) pins A (3) to B (4) and pins C (5) to D (6). Forcable-activated lock, measure resistance between harness12369684 jack (2) pins A (3) to B (4).5. Did multimeter read more than 0 ohms either time?YESNOC2YN1. Replace harness 12354722 (forsolenoid-activated lock) or 12369685(for cable- activated lock) circuit369A and/or ground circuit(WP 0374 00).2. Verify no faults found.0054 00-4
