236

TM 9-2350-247-20-1 TRANS LOW OIL PRESS INDICATOR MALFUNCTIONS (M548A3)—Continued 0055 00 BY 1. Remove wiring harness 12313482 plug (1) from wiring harness 12313483 jack (2) at carrier bulkhead. 2. Is TRANS LOW OIL PRESS indicator still on? YES NO BYN 1. Replace wiring harness 12313482 (WP 0297 00). 2. Verify no faults found. 2BY 1. Remove circuit 366 plug (1) from TRANS LOW OIL PRESS indicator (2) behind instrument panel. 2. Is TRANS LOW OIL PRESS indicator still on? YES NO 2BYN 1. Replace wiring harness 12313483 (WP 0297 00). 2. Verify no faults found. 0055 00-3
