TM 9-2350-247-20-1
HI TEMP TRANS OIL INDICATOR COMES ON (M548A3)
0033 00
INITIAL SETUP:
Maintenance Level
Unit
Tools and Special Tools
General Mechanic’s Tool Kit (WP 0541 00, Item 57)
Pressure Gauge Kit (WP 0541 00, Item 34)
Personnel Required
Unit Mechanic
References
See your -10
See your PMCS
Equipment Condition
Engine stopped (see your -10)
Carrier blocked (see your -10)
Transmission in SL (see your -10)
Transmission oil level checked (see your PMCS)
Cab floor plates raised (WP 0395 00)
T
1. Allow power plant to cool.
2. Does HI TEMP TRANS OIL light go off?
YES
NO
TN
1. Go to HI TEMP TRANS OIL
indicator malfunctions WP 0057 00.
Y
1. Run carrier until HI TEMP TRANS OIL light comes on.
2. Stop carrier (see your -10).
3. Run engine at 1500 rpm for 5 minutes.
4. Is HI TEMP TRANS OIL indicator light still on?
YES
NO
YN
1. Return carrier to service.
2. No faults found.
0033 00-1
